美国专利产品

Dimensions尺寸: 8.5" Depth x 12.5" Width x 25.5" Height

Weight重量: 66 lbs (with bath) or 61 lbs (with carbon block)

Pressure Range压力范围: Atm to 2,000 psi

Sample Size样品量: 32 to 78 ml

Resolution:重复性 0.01% of full scale range or better

Temperature Range温度范围: Ambient (20 °F with chilling device) to 500 °F

Speed Range转速范围: 0.0001 to 1,100 rpm continuous

Frequency Range频率范围: 0.01 to 5 Hz (Optimized at 0.2 to 3 Hz)

Amplitude Range振幅范围: 0.1%  to 500 % (Optimized at 0.2% to 500%)

Shear Rate Range剪切速率范围: 0.00004 to 1870 sec^-1

Shear Stress Range剪应力范围: 1 to 15,000 dyn/cm²

Viscosity Range粘度范围: 0.5 to 5,000,000 Centipoise

Torque扭矩:  14 μN.m to 100 mN.m

Repeatability重复性: ±0.05% of full scale range or better

Power Voltage电源电压: 120V or 240V (with transformer)

Construction结构: Hastelloy C wetted material 哈氏合金C润湿材料

Power Frequency电源频率: 50 Hz or 60 Hz
